10. Machine room view and part list
NO PART NAME NO PART NAME
1 COMPRESSOR 11 CASE VAPORI
2 BASE COMP AS 12 BAND RELAY
3 FIX COMP WASH 13 RELAY COVER
4 ABSORBER COMP 14 PIPE CONN SUC
5 PIPE CONN HOT 15
6 D TIMER AS or POWER BOX AS
7 CORD POWER AS
8 DRYER AS(R-12 or R-134a)
9 TAPE COTTON
10 CAP HOSE DRAIN
