9. MAIN COMPONENTS

MAIN COMPONENTS

1. COMPRESSOR

Refrigerant R-12

Voltage 110V/60Hz 127V/60Hz 220~240V/50Hz 220V/50Hz 220V/60Hz

Comp. model CL23YE-3-C CL23YE-2-C SL25YE-5-C KL25YE-5-C PL23YE-4

Part code 3951123C10 3957123C20 3954125C80 3958125C50 3956123841

Starting type CSIR CSIR RSIR CSIR RSCR

Refrigerant(g) 130

2. SWITCH RELAY AS

Refrigerant R-12

Voltage 110V/60Hz 127V/60Hz 220~240V/50Hz 220V/50Hz 220V/60Hz

Relay model 427THBYY-52 414THBYY-52 276THBYY-52 724RFBYY-52 197SHBYY-52

Part code 3018114660 3018114640 3018114630 3018115300 3018114620

Starting type CSIR CSIR RSIR CSIR RSCR

Refrigerant R-134a

Voltage 110V/50, 60Hz 110V/60Hz 115V/60Hz 220~240V/50Hz

Comp. model HBL23YE-C HBL23YE-3-C HBL23YE-3-C HSL25YE-5-C

Part code 3952123L00 3952123L30 3952123L30 3954125L50

Starting type CSR CSR CSR CSIR

Refrigerant(g) 120

Refrigerant R-134a

Voltage 110V/50, 60Hz 110V/60Hz 115V/60Hz 220~240V/50Hz

Relay model 414THBYY-52 427THBYY-52 427THBYY-52 232THBYY-52

Part code 3018114610 30181146 3018114600 3018114650

Starting type CSR CSR CSR CSIR

3. STARTING CAPACITOR

Refrigerant R-12

Voltage 110V/60Hz 127V/60Hz 220~240V/50Hz 220V/50Hz 220V/60Hz

Spec. 140V/100µF 140V/100µF X 350V/25µF X

Part code 3016400400 3016400400 X 400EL16110 X

Refrigerant R-134a

Voltage 110V/50, 60Hz 110V/60Hz 115V/60Hz 220~240V/50Hz

Spec. 414THBYY-52 427THBYY-52 427THBYY-52 232THBYY-52

Part code 3018114610 30181146 3018114600 3018114650
