10-1. PART LIST
13
PART LIST
No. PART CODE PART NAME DESCRIPTION Q’TY REMARK
1 PFCCCUG080 ASSY CAB URT PRE+URT 1 R-11
PFCCCUG085 R-141B
1-1 3017001700 EVAPORATOR SAS 1
1-2 3018111800 SWITCH BI-METAL AS 1
1-3 3017200600 FUSE TEMP AS 1 250V/10A, 77˚C
1-4 4017Z90590 FIXTURE FUSE TEMP 1
1-5 4017Z73570 COVER DEFR HTR *T AI T0.4 1
1-6 – HEATER D AS 1
1-7 4017Z73580 COVER DEFR HTR *U AI T0.4 1
1-8 3012906700 HINGE *U AS P/D T3.2 1
1-9 7650602011 BOLT HEX M6 X 20 2
2 3010313500 BASE COMP AS 1
2-1 3010302800 BASE COMP SAS SBHG-1 1
2-2 3010100201 ABSORBER COMP NR-A 4
2-3 – COMPRESSOR 1
2-4 4019H09030 SPECIAL WASHER SPG T1.0 4
2-5 – SWITCH RELAY AS 1
2-6 3816100100 BAND RELAY SK-5, T0.7 1
3 – MOTOR F AS 1
3-1 4017Z32244 COVER FAN MOTOR(B) HIPS 1
3-2 4017Z08430 ABSORBER MOTOR EPR-B3 2
3-3 – MOTOR AS 1
3-4 4017Z32233 COVER FAN MOTOR(C) HIPS 1
3-5 4019H32230 COVER FAN MOTOR(A) HIPS 1
3-6 4019H10310 FAN ABS 1
3-7 4019H100600 RING FIX FAN STS 27 1
4 3018906100 LOUVER AS
4-1 3013327800 INSU F LUVR AS F-PS 1
4-2 3013401000 KNOB F LUVR PP 1
4-3 3018905700 LOUVER F PP 1
5 3016908700 DUCT R MULT AS 1
5-1 3016907900 DUCT R MULTI PP 1
5-2 3018301300 THERMOSTAT PFN-175D-01 1
BU-274
5-3 7121400811 SCREW TAPPING T2S PAN 4 X 8 2
5-4 3017903200 SOCKET R LAMP AS 1
5-5 3013327900 INSU R MULT DUCT AS F-PS 1
5-6 4008Z14310 KNOB C/S ABS 1
6 – ASSY F DOOR 1
6-1 PFDT1UG070 DOOR F URT AS PRE+URT 1 R-11
PFDT1UG075 R-141B
6-1-1 3015200900 STOPPER *M HI POM 1
