29
EXPLODED VIEW AND PARTS LIST
1. FR-4506K
NO PART CODE PART NAME PART DESCRIPTION Q’ TY REMARK
1 3010031200 ASSY CAB URT FRM(P)-371 1
2 3012911500 HINGE*T SPCC T2 1
3 3012905400 SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
4 3011449800 COVER *T HI HIPS 1
5 3012911400 HINGE *M AS DC-2 ZN 1
6 3016001220 SPECIAL BOLT M 6X20 SWCH22A(WH) 2
7 FOOT ADJUST AS 2
8 3012911300 HINGE *U AS SPHC-H T4 1
9 3012905400 SPECIAL BOLT T/U 6X22 SWCH22A(WH) 3
10 3011450200 COVER CAB BRKT PP 1
11 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 2
12 3010103700 ABSORBER SUC P NR 1
13 3011302012 CORD POWER AS 1 250V/16A
14 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 1
15 7001400865 SCREW MACHINE PAN 4X8 BSNI 1
16 3013202700 HOSE DRN B PP 1
17 3012405800 GRILLE SBHG1 1
18 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 5
19 3016805500 DRYER AS 1
20 3014433500 PIPE WICON TSW OD4.76XT0.7XL14560 1
21 3011200400 CLAMP FAN SUS304 1
22 3011800400 FAN 1
23 MOTOR C 1
24 3012004400 FIXTURE C MOTR SUS 1
25 3010102100 ABSORBER C MOTR NR,FRB-5350NT 1
26 3011161900 CASE VAPORI PP 1
27 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 2
28 COMPRESSOR 1
29 3018116610 SWITCH P-RELAY AS 1
30 3012610000 CLAMP BRAND RELAY SK-5 T0.7 1
31 3010318400 BASE COMP SBHG1 1
32 3016500000 CASTER *B PP OD36XL37 2
33 3014902900 SHAFT CASTER *B "SPH, T1, OD6XL51" 2
34 3016003300 SPECIAL BOLT T2 M6.5X20 4
35 3012007900 FIXTURE MOTR B PP 1
36 MOTOR F 1
37 3011802200 FAN ABS(OD110) 1
38 7112401211 SCREW TAPPING T1TRS 4X12 MFZN 2
39 3013336310 INSU F LUVR EPS 1
40 3013402600 KNOB F CONTL PP 1
41 3018910400 LOUVER F HIPS 1
42 7112401611 SCREW TAPPING T1TRS 4X16 MFZN 2
43 3010924600 CAP F-LUVR HIPS T2.3 2
44 3017821600 SHELF F HIPS T3.0 1
45
3013001420 HOLDER ICE AS HIPS 1
3012201900
3010518900
FRAME ICE CASE SAS 1
47
BOX ICE 1
48
49
7112401208 SCREW TAPPING T1 TRS 4X10 SUS 1
✔ Caution :
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list.
So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center
(http://svc.dwe.co.kr)
