1 DOOR HOOK
Hook automatically locks and holds the door when the door
shuts. If the door opens while the oven is operating, the
oven will stop operating immediately.
2 DOOR SEAL
Door seal prevents the microwave leakage from the oven
cavity.
3 DOOR VIEWING SCREEN
Food, inside of oven, can be observed through the door
viewing screen. It is designed that the microwave cannot
pass through the screen.
4 TOP HEATER
Top heater turns on if any of heater related mode operates.
5 OVEN FRONT PLATE
6 CONVECTION INLET
7 OVEN LAMP
Oven lamp turns on anytime the door opens and oven
operates.
8 SAFETY INTERLOCK SYSTEM
9 CONTROL PANEL
0 METAL RACK
q COUPLER
Coupler located at the center of the oven cavity and it
couples between the motor and the glass tray.
w ROLLER GUIDE
Roller guide must be used anytime with the glass tray.
e GLASS TRAY
Glass tray is made of special heat resistant glass material. It
must be always properly fitted with the coupler and the roller
guide.
