1 Door hook - When the door is closed, it will
automatically lock shut. If door is opened while oven is
operating, the magnetron will immediately stop
operating.
2 Door viewing screen - Allows viewing of food. The
screen is designed so that light can pass through, but
not the microwave.
3 Metal rack
4 Top heater - Turns on when convection, grill and
combi cooking is selected.
5 Oven lamp - Automatically turns on during oven
operating.
6 Safety interlock system
7 Control panel
8 Turntable tray - Rotates during cooking and ensure
even distribution of Microwaves.
It can also be used as a cooking utensil.
9Roller guide - This must always be used for cooking
together with the turntable tray.
0 Coupler - This fits over the shaft in the center of the
ovens cavity floor. This is to remain in the oven for all
cooking.
q Convection fan
w Oven front plate
e Door seal - Door seal maintains the microwave
energy within the oven cavity and prevents microwave
leakage.
