5. To remove control panel parts.
(1) Remove the screw which secure the control panel,
push up two snap fits and draw forward the control
panel assembly.
(2) Remove the door open lever ¤ºfrom the control panel ¤Œ.
(3) Remove two screws ¤ıwhich secure the timer assembly ¤ .
(4) Remove the timer assembly ¤ .
(5) Pull out the timer knob ¤ from the timer assembly ¤ .
(6) Pull out the timer coupler ¤ from the timer assembly ¤ .
(7) Remove the screw ¤ pull out the switch micro ¤ .
(8) Remove the screw ¤æwhich secure the V.P.C. coupler ¤ .
(9) Pull out the V.P.C couple ¤ and V.P.C knob ¤Ø from the control panel ¤Œ.
(10) Remove the screw ¤ pull out the switch micro ¤ .
(11) Remove the door open button ¤ and button spring ¤Łfrom the control panel ¤Œ.
(12) Reverse the above steps for reassembly.
