2 Port and Indicator
2.1 Front Panel
The following figures are for reference only, and might differ from the actual product.
Figure 2-1 Front panel (with PoE)
Figure 2-2 Front panel (without PoE)
Following are all the ports and indicators on the front panel of the 4/8-port unmanaged hardened
switch. The actual device might only have some of these ports and indicators.
Table 2-1 Description of front panel
No. Description
1
10 Mbps/100 Mbps or 10 Mbps/100 Mbps/1000 Mbps self-adaptive PoE
Ethernet ports.
