Dahua IPC-HDW3200S User Manual

7
2 Structure
2.1 Components
You can refer to the following figure for multiple-function combination cable information. See Figure
2-1.
Figure 2-1 Multiple-function combination cable
Please refer to the following sheet for detailed information.
No.
Port
Name
Connector
Note
4
LAN
Network
port
Ethernet
To connect to standard
Ethernet.
5
DC12V
DC 12V
power
To connect to DC12V power
supply.
2.2 Framework and Dimension
Component
Component Name
Component 1
Device lens
Component 2
Dome body
Component 3
Dome enclosure

Dahua IPC-HDW3200S Specifications

General

Brand	Dahua
Model	IPC-HDW3200S
Category	Security Camera
Language	English
