Dahua IPC-HDW3200S User Manual

2
1.3 Specifications
Please refer to the following sheet for network camera performance specification.
Model
Parameter
IPC-HDW2100
System
Main Processor
TI Davinci high performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
Pixel
1280(H)*960(V)
Day/night
Support IR-CUT switch
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
Off/BLC/WDR (1-100 adjustable)/HLC(anti-flicker is outdoor and is
valid only when exposure mode is auto with range 1-100)
Exposure Mode
Manual/Auto
It ranges from 1/3 to 1/10000.
Video
Compression
Standard
H.264/H.264H/H.264B/MJPEG
Note: Some versions do not support H.264H.
Video Frame
Rate
PAL:
Main stream (1280*960@15fps),
extra stream ( 704*576@15fps)
Main stream (1280*720@25fps),
extra stream ( 704*576@25fps)
NTSC:
Main stream (1280*960@15fps),
extra stream ( 704*480@15fps)
Main stream (1280*720@30fps),
extra stream ( 704*480@30fps)
Video Bit Rate
H.264: 56Kbps-6144Kbps
MJPEG: adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, camera masking.
Lens
2.8mm, 3.6mm, 6mm, 8mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
Rec
ord
Record Priority
Manual >External alarm>Video detect>Schedule
