Rear Panel
Rear panel
Table 1-2
R
ea
r panel
No.
Description
No.
Description
1
Analog camera port 1.
6
VTH cascading port 1.
2
VTO port 1.
7
VTH cascading port
2.
3
VTO port 2.
8
VTO hanging slot.
4
Power input.
9
Wires.
5
Analog camera port 2.
–
–
7
