User's Manual
140
5.9.6.2 Configuring IVS
5.9.6.2.1 Tripwire
Background Information
When the detection target crosses the warning line along the set direction, the system
performs an alarm linkage action.
Procedure
Step 1 Select Main Menu > Analytics+ > Parameters > IVS.
Figure 5-106 IVS
Step 2 Select channel and Analytics+ type.
Step 3 Click Add to add a rule.
Step 4 On the Type list, select Tripwire.
Step 5 Draw the detection rule.
1) Click to draw a straight line or a curve on the security video image.
Right-click the image to stop drawing.
To Next Page
