Dahua NVR41-P Series User Manual

196
4.3.7 Fisheye (Optional)
Please note this function is for some series only.
4.3.7.1 Fisheye de-warp during preview interface
The fisheye camera (panoramic camera) has wide video of angle but its video is serious distorted. The
de-warp function can present the proper and vivid video suitable for human eyes.
On the preview interface, select fisheye channel and then right click mouse, you can select fish eye. See
Figure 4-78.
Figure 4-78
Now you can see an interface shown as in Figure 4-79. You can set fish eye installation mode and display
mode.
Note
 For the non-fish eye channel, system pops up dialogue box to remind you it is not a fish eye channel
and does not support de-warp function.
 If system resources are insufficient, system pops up the corresponding dialogue box too.
