4 | About the box
Installer reference guide
21
2MXM-A9, 3MXM-A9, 4MXM-A9, 5MXM-A9
R32 Split series
4P600463-7G – 2022.09
4 About the box
Keep the following in mind:
▪ At delivery, the unit MUST be checked for damage and completeness. Any
damage or missing parts MUST be reported immediately to the claims agent of
the carrier.
▪ Bring the packed unit as close as possible to its final installation position to
prevent damage during transport.
▪ Prepare in advance the path along which you want to bring the unit to its final
installation position.
▪ When handling the unit, take into account the following:
Fragile, handle the unit with care.
Keep the unit upright in order to avoid damage.
4.1 Outdoor unit
4.1.1 To unpack the outdoor unit
4.1.2 To handle the outdoor unit
CAUTION
To avoid injury, do NOT touch the air inlet or aluminium fins of the unit.
