5 About the unit
INFORMATION
It is NOT possible to connect an indoor unit of 1 room only. Be sure to connect
indoor units of at least 2 rooms.
INFORMATION
Depending on the units and/or the installation conditions, it might be necessary to
connect electrical wiring before you can charge refrigerant.
The Hybrid for Multi or the DHW generator for Multi are considered as 1 room
connection.
For the correct combination, see the combination table and the installation manual
of the Hybrid for Multi or the DHW generator for Multi.
WARNING: MILDLY FLAMMABLE MATERIAL
The refrigerant inside this unit is mildly flammable.
INFORMATION
For the operation limits see the latest technical data of the outdoor unit on the
regional Daikin website (publicly accessible).
5.1 Identification
NOTICE
When installing or servicing several units at the same time, make sure NOT to switch
the service panels between different models.
5.1.1 Identification label: Outdoor unit
Location
