9
English
AUTO · DRY · COOL · HEAT · FAN Operation
The air conditioner operates with the operation mode of your choice.
From the next time on, the air conditioner will operate with the same
operation mode.
To start operation
Press 1. and select a operation mode.
Each pressing of the button advances the mode setting in •
sequence.
: AUTO : HEAT
: DRY : FAN
: COOL
Press 2. .
“ • ” is displayed on the LCD.
The OPERATION lamp lights up. •
To stop operation
Press 3. again.
“ • ” disappears from the LCD.
Then OPERATION lamp goes off.•
To change the temperature setting
Press 4. .
AUTO or COOL or HEAT operation DRY or FAN operation
Press
to raise the temperature and
press to lower the temperature.
The temperature setting is not variable.
Set to the temperature you like.
01_EN_3P272441-5.indb 901_EN_3P272441-5.indb 9 11/30/2010 4:01:29 PM11/30/2010 4:01:29 PM
