Daikin FXAQ07MVJU Engineering Data

EDUS39-600-F6 Specifications
FXAQ-M 3
2. Specifications
Wall Mounted Type
Notes:
1. Nominal cooling capacities are based on the following conditions:
Return air temperature: 80°FDB, 67°FWB
Outdoor temperature: 95°FDB
Equivalent ref. piping length: 25ft (Horizontal)
2. Nominal heating capacities are based on the following conditions:
Return air temperature: 70°FDB.
Outdoor temperature: 47°FDB, 43°FWB
Equivalent ref. piping length: 25ft / 7.5 m (Horizontal)
3. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
4. Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of installation conditions.
5. Refer to page 10 for Power Input.
Model FXAQ07MVJU FXAQ09MVJU FXAQ12MVJU
Cooling Capacity
1
Btu/h 7,500 9,500 12,000
Heating Capacity
2
Btu/h 8,500 10,500 13,500
Casing Color White (3.0Y8.5/0.5) White (3.0Y8.5/0.5) White (3.0Y8.5/0.5)
Dimensions: (H×W×D) in (mm)
11–3/8 × 31–1/4 ×9” (289 x 793.7 x
228.6 mm)
11–3/8 × 31–1/4 × 9” (289 x 793.7 x
228.6 mm)
11–3/8 × 31–1/4 × 9” (289 x 793.7 x
228.6 mm)
Coil (Cross
Fin Coil)
Rows×Stages×FPI 2×14×17 2×14×17 2×14×17
Face Area ft² 1.73 1.73 1.73
Fan
Model QCL9661M QCL9661M QCL9661M
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output kW 0.04 0.04 0.04
Airflow Rate (H/L) cfm 260/160 280/175 300/180
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for Cooling
and Heating
Microprocessor Thermostat for Cooling
and Heating
Microprocessor Thermostat for Cooling
and Heating
Sound Absorbing Thermal Insulation Material
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Air Filter Resin Net (Washable) Resin Net (Washable) Resin Net (Washable)
Piping
Connections
Liquid Pipes in / mm φ1/4” / 6.4 mm (Flare Connection) φ1/4” / 6.4 mm (Flare Connection) φ1/4” / 6.4 mm (Flare Connection)
Gas Pipes in / mm φ1/2” / 12.7 mm (Flare Connection) φ1/2” / 12.7 mm (Flare Connection) φ1/2” / 12.7 mm (Flare Connection)
Drain Pipe in / mm
VP13
External Dia. 11/16” (17.5 mm)
Internal Dia. 1/2” (12.7 mm)
VP13
External Dia. 11/16” (17.5 mm)
Internal Dia. 1/2” (12.7 mm)
VP13
External Dia. 11/16” (17.5 mm)
Internal Dia. 1/2” (12.7 mm)
Machine Weight (Mass) Lbs 25 25 25
Sound Level (H)
4
dBA363738
Safety Devices Fuse Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A Series R-410A Series R-410A Series
Standard Accessories
Operation Manual, Installation Manual,
Installation Panel, Paper Pattern for
Installation, Insulation Tube, Clamps,
Screws.
Operation Manual, Installation Manual,
Installation Panel, Paper Pattern for
Installation, Insulation Tube, Clamps,
Screws.
Operation Manual, Installation Manual,
Installation Panel, Paper Pattern for
Installation, Insulation Tube, Clamps,
Screws.
Drawing No. C:3D046038A
