■English 25
1. Open the front panel. (page 24.)
2. Pull out the air filters.
• Push a little upwards the tab at the center of
each air filter, then pull it down.
3. Take off the air-purifying filter with photocatalytic
deodorizing function.
• Press the top of the air-cleaning filter onto the tabs (3 at top). Then
press the bottom of the filter up slightly, and press it onto the tabs
(2 at bottom).
4. Clean or replace each filter.
See figure.
5. Set the air filter and the air-purifying filter with
photocatalytic deodorizing function as they were and close
the front panel.
• Press the front panel at both sides and the center.
■
Air Filter
1. Wash the air filters with water or clean them with vacuum cleaner.
• If the dust does not come off easily, wash them with neutral detergent thinned
with lukewarm water
and then allow them to dry in shade.
• It is recommended to clean the air filters every two weeks.
■
Air-purifying filter with photocatalytic deodorizing function (gray)
The Air-purifying filter with photocatalytic deodorizing function can be renewed by washing it with water
once every 6 months. We recommend replacing it once every 3 years.
[ Maintenance ]
1. Remove dust with a vacuum cleaner and wash lightly with water.
2. If it is very dirty, soak it for 10 to 15 minutes in water mixed with a neutral cleaning agent.
3. After washing, shake off remaining water and dry in the shade.
4. Since the material is made out of paper, do not wring out the filter when removing
water from it.
[ Replacement ]
1. Remove the tabs on the filter frame and replace with a new filter.
• Dispose of the old filter as flammable waste.
Filters
tabs (2 at bottom)
tabs (3 at top)
01_EN_3P194537-2B.fm Page 25 Monday, July 2, 2007 5:19 PM
To Next Page
