16
ENGLISH
TECHNICAL SPECIFICATIONS
There are countless methods for evaluating speakers from a technical point of view resulting in
technical specifications, graphs and characteristics. However, none of them actually represent how
a speaker really sounds and the realism it is able to reproduce. It is up to the individual to decide
whether one speaker sounds better than another. Still, we would like to present the objective
technical specifications which we find most relevant.
But remember, technical data reveal nothing about how music will sound when reproduced by a
given music system. DALI speakers are designed to reproduce music as true to the source as pos
-
sible. But it is up to you to decide what you think of the sound quality – trust your senses!
Enjoy your new speakers!
PHANTOM VOKAL
Frequency Range +/- 3 dB [Hz] 72 – 33,000
Sensitivity 2.83V/1m [dB] 89.0
Nominal impedance [ohms] 8
Maximum SPL [dB] 108
Crossover Frequencies [Hz] 3,000, 13,000
Enclosure type Closed box
Recommended placement In wall/ceiling
Recommended Amp. Power [W
1
] 30 – 150
High Frequency Drivers (mm)
Soft dome
2
1 x 28
Ribbon 1 x 17 x 45
Low frequency Driver(s) 2 x 5”
Terminals Single-wire
Dimensions (W x H x D) (cm) 27 x 44 x 11
Dimensions (W x H x D) (inch) 10.8 x 17.2 x 4.4
Cut-out Dimensions (W x H x D) (cm) 39.6 x 23.3 x 9.5
Cut-out Dimensions (W x H x D) (inch) 15.6 x 9.2 x 3.8
Weight (kg/lbs) 6.2 / 13.6
Accessories 3 mm Allen wrench
3 mm Allen bit
mounting template
protective template for painting
white logo badge
Finishes White, NCS S0502-Y, gloss 20
1
RMS Watt
2
Silk
