Danfoss 103 User Manual

2
INDEX
Index
Installation
Product speci cation 3
Installation 4-5
Wiring 6
User
What is a timeswitch? 7
Your timeswitch 8
Setting the time of day 9
Setting the programme 9-10
Selecting operating mode 11
Temporary overrides 12
Contact details 16
For a large print version of these instructions
please call Marketing on 01234 364 621.
Danfoss can accept no responsibility for possible errors in catalogues, brochures, and other printed
material. All trademarks in this material are property of the respective companies. Danfoss and the
Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
®
Certification Mark

Danfoss 103 Specifications

General

Mounting	DIN Rail
Voltage	230V AC
Contact	1 changeover contact
Current rating	16 A
Number of channels	1
Timer range	24 hours
Protection class	IP20
Switching Type	SPST (Single Pole Single Throw)
