AK-PC 551 User Guide RS8GY302 © Danfoss 2015-06 21
Alarm list
Alarm text Reason Priority
setting
Default
value
General alarms
Standby mode (Main sw. OFF) Alarm when control is stopped by internal or external Main Switch (DI input "Main Switch") Standby mode Normal
PoA sensor error Pressure transmitter signal from PoA defective
Sensor error Normal
PoB sensor error Pressure transmitter signal from PoB defective
S4A sensor error Temperature signal from S4A media temp. sensor defective
S4B sensor error Temperature signal from S4B media temp. sensor defective
SsA sensor error Temperature signal from SsA suction gas temp. defective
SsB sensor error Temperature signal from SsB suction gas temp. defective
SdA sensor error Temperature signal from SdA discharge gas temp. Sd defective
SdB sensor error Temperature signal from SdB discharge gas temp. Sd defective
Pc sensor error Pressure transmitter signal from Pc defective
S7 sensor error Temperature signal from S7 media sensor on condenser defective
Sc3 sensor error Temperature signal from Sc3 air on condenser defective
Sd Comp. 1A sensor error Temperature signal from "Sd comp. 1A" discharge gas temp. on digital scroll/Stream compressor is
defective
Sd Comp. 1B sensor error Temperature signal from "Sd comp. 1B" discharge gas temp. on digital scroll/Stream compressor is
defective
Saux - sensor error Temperature signal from Saux thermostat sensor is defective
Refrigerant not selected Alarm if no refrigerant has been selected Refrigerant not set Normal
Output in manual mode An output is set in manual mode Output in MAN mode Normal
IO conguration error Not all inputs and output functions have been assigned to hardware Inputs or outputs* (can not be set) Normal
GA1 - "Alarm text" Alarm on general alarm input DI 1 (DI input "Gen. Alarm 1 - alarm text depend upon congured text) General alarm 1 Normal
GA2 - "Alarm text" Alarm on general alarm input DI 2 (DI input "Gen. Alarm 2 - alarm text depend upon congured text) General alarm 2 Normal
GA3 - "Alarm text" Alarm on general alarm input DI 3 (DI input "Gen. Alarm 3 - alarm text depend upon congured text) General alarm 3 Normal
Suction A alarms
PoA Low suction pressure Minimum safety limit for suction pressure PoA has been violated
Low pressure PoA Normal
LP A safety switch cut out Low safety limit for external low pressure switch has been violated (DI input "LP switch A")
PoA High suction pressure High alarm limit for PoA has been exceeded High pressure PoA Critical
SsA High superheat Superheat in suction line A too high (measured by PoA and SsA)
Superheat A Normal
SsA Low superheat Superheat in suction line A too low (measured by PoA and SsA)
SdA High discharge temp. Safety prevention limit for SdA discharge temperature has been exceeded (10K below safety limit) High disch. temp.SdA Critical
Comp. 1A High disch. temp Safety limit for discharge gas temperature of digital scroll/Stream/CRII compressor has been exceeded
Compressor safety A Normal
Compressor 1-8A safety cut
out
Compressor no. 1-8 A has been cut out on general safety input (DI input "Comp.1-8 A safety")
Suction B alarms
PoB Low suction pressure Minimum safety limit for suction pressure PoB has been violated Low pressure PoB Normal
LP B safety switch cut out Low safety limit for external low pressure switch has been violated (DI input "LP switch B")
PoB High suction pressure High alarm limit for PoB has been exceeded High pressure PoB Critical
SsB High superheat Superheat in suction line B too high (measured by PoB and SsB)
Superheat B Normal
SsB Low superheat Superheat in suction line B too low (measured by PoB and SsB)
SdB High discharge temp. Safety prevention limit for SdB discharge temperature has been exceeded (10K below safety limit) High disch. temp.SdB Critical
Comp. 1B High disch. temp Safety limit for discharge temperature of digital scroll/Stream compressor has been exceeded
Compressor safety B Normal
Compressor 1-4B safety cut
out
Compressor no. 1-4 B has been cut out on general safety (DI input "Comp.1-4 B safety")
Condenser alarms
Pc High condensing pressure High prevention safety limit for condensing pressure Pc has been violated (3K below safety limit)
High pressure Pc Critical
HP safety switch cutout High safety limit for external high pressure switch has been violated (DI input "HP switch")
Common fan safety cut out A Fan is reported defective via common safety input (DI input "Fan safety")
Fan safety Normal
Fan 1 safety cut out Fan no. 1-8 is reported defective via individual safety input (DI input "Fan 1-8 safety")
* The alarm "IO conguration error" is activated if not all IO functions have been assigned to a hardware Input or output.
Often the reason is that too many functions have been selected via the conguration of the controller.
Go to the menu point "Main menu => IO status => IO summary".
In this screen you can see if you have congured too many functions of a certain type - indicated by an exclamation mark " ! "
Please refer to the screen example, were too many DO functions have been congured.
Solve the problem by adapting the DO functions to the max. No of DO outputs.
Sensor alarms
Sensor alarms shut o automatically when the sensor has been O.K. for 10 minutes.
If you have corrected the sensor error and want to perform a manual, forced removal of the alarm, go to the “Alarm detail display”
Press and hold the “X” key for 2 seconds here.
