4 Control system
The heat pump has an integrated control system which automatically
calculates the heating and cooling demand in the house to ensure that
the correct amount of heating and cooling is produced and emitted
where necessary.
The control panel is operated using a keypad and information is shown
in a display and by an indicator.
The information in the display and menus will vary depending
on the menu selection made and connected accessories.
1. Keypad
2.
Indicator
3. Display
4.1 Keypad
+ Plus sign used to scroll up a menu and increase the values.
- Minus sign used to scroll down a menu and reduce the values.
> Right arrow used to select a value or open a menu.
< Left arrow to cancel selection or exit a menu.
4.2 Indicator
The indicator at the bottom of the control panel has three modes:
12 – User manual VUGFB102
