Danfoss VLT 5000 Instruction Manual

21
MG.60.N1.22 - VLT is a registered Danfoss trademark
VLT
®
5000 / VLT
®
6000 HVAC / VLT
®
8000 AQUA
Network
Termination
Option
Terminator
and Service
Switch
Locations
The option of using termination on the
LonWorks card is provided. The option card
has a termination resistor built-in which is
activated by the terminator switches. Use of
the terminator is optional, depending upon the
network configuration. If termination is
provided elsewhere in the network, the
termination function should be OFF.
Terminator switches position functions are
provided in the table below.
Switch Position Functions
TT
TT
T
erminationermination
erminationermination
ermination
Pos 1Pos 1
Pos 1Pos 1
Pos 1
Pos 2Pos 2
Pos 2Pos 2
Pos 2
No termination Net Term OFF Net Term OFF
(Factory setting) (Factory setting)
Single termination Net Term ON Net Term OFF
Double termination Net Term ON Net Term ON
TT
TT
T
erminator Switcheserminator Switches
erminator Switcheserminator Switches
erminator Switches
Service Pin SwitchService Pin Switch
Service Pin SwitchService Pin Switch
Service Pin Switch
Service Pin SwitchService Pin Switch
Service Pin SwitchService Pin Switch
Service Pin Switch
OFF
1
2
Free Topology LonWorks Control Card
