Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing operation
Conver-
sion index
Type
0-6* Password
0-60 Main Menu Password 100 N/A 1 set-up TRUE 0 Uint16
0-61 Access to Main Menu w/o Password [0] Full access 1 set-up TRUE - Uint8
0-65 Personal Menu Password 200 N/A 1 set-up TRUE 0 Uint16
0-66 Access to Personal Menu w/o Password [0] Full access 1 set-up TRUE - Uint8
0-7* Clock Settings
0-70 Date and Time SR All set-ups TRUE 0
TimeOf-
Day
0-71 Date Format [0] YYYY-MM-DD 1 set-up TRUE - Uint8
0-72 Time Format [0] 24 h 1 set-up TRUE - Uint8
0-74 DST/Summertime [0] Off 1 set-up TRUE - Uint8
0-76 DST/Summertime Start SR 1 set-up TRUE 0
TimeOf-
Day
0-77 DST/Summertime End SR 1 set-up TRUE 0
TimeOf-
Day
0-79 Clock Fault null 1 set-up TRUE - Uint8
0-81 Working Days null 1 set-up TRUE - Uint8
0-82 Additional Working Days SR 1 set-up TRUE 0
TimeOf-
Day
0-83 Additional Non-Working Days SR 1 set-up TRUE 0
TimeOf-
Day
0-89 Date and Time Readout 0 N/A All set-ups TRUE 0
VisStr[2
5]
6.4.3 Load/Motor 1-**
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing operation
Conver-
sion index
Type
1-0* General Settings
1-00 Configuration Mode null All set-ups TRUE - Uint8
1-01 Motor Control Principle null All set-ups FALSE - Uint8
1-03 Torque Characteristics [3] Auto Energy Optim. VT All set-ups TRUE - Uint8
1-1* Motor Selection
1-10 Motor Construction [0] Asynchron All set-ups FALSE - Uint8
1-2* Motor Data
1-20 Motor Power [kW] SR All set-ups FALSE 1 Uint32
1-21 Motor Power [HP] SR All set-ups FALSE -2 Uint32
1-22 Motor Voltage SR All set-ups FALSE 0 Uint16
1-23 Motor Frequency SR All set-ups FALSE 0 Uint16
1-24 Motor Current SR All set-ups FALSE -2 Uint32
1-25 Motor Nominal Speed SR All set-ups FALSE 67 Uint16
1-28 Motor Rotation Check [0] Off All set-ups FALSE - Uint8
1-29 Automatic Motor Adaptation (AMA) [0] Off All set-ups FALSE - Uint8
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs) SR All set-ups FALSE -4 Uint32
1-31 Rotor Resistance (Rr) SR All set-ups FALSE -4 Uint32
1-32 Stator Reactance (Xs) SR All set-ups FALSE -4 Uint32
1-33 Stator Leakage Reactance (X1) SR All set-ups FALSE -4 Uint32
1-34 Rotor Leakage Reactance (X2) SR All set-ups FALSE -4 Uint32
1-35 Main Reactance (Xh) SR All set-ups FALSE -4 Uint32
1-36 Iron Loss Resistance (Rfe) SR All set-ups FALSE -3 Uint32
1-39 Motor Poles SR All set-ups FALSE 0 Uint8
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed 100 % All set-ups TRUE 0 Uint16
1-51 Min Speed Normal Magnetising [RPM] SR All set-ups TRUE 67 Uint16
1-52 Min Speed Normal Magnetising [Hz] SR All set-ups TRUE -1 Uint16
1-55 V/f Characteristic - V SR All set-ups TRUE -1 Uint16
1-56 V/f Characteristic - f SR All set-ups TRUE -1 Uint16
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation 100 % All set-ups TRUE 0 Int16
1-61 High Speed Load Compensation 100 % All set-ups TRUE 0 Int16
1-62 Slip Compensation 0 % All set-ups TRUE 0 Int16
1-63 Slip Compensation Time Constant SR All set-ups TRUE -2 Uint16
1-64 Resonance Dampening 100 % All set-ups TRUE 0 Uint16
1-65 Resonance Dampening Time Constant 5 ms All set-ups TRUE -3 Uint8
1-7* Start Adjustments
1-71 Start Delay 0.0 s All set-ups TRUE -1 Uint16
1-73 Flying Start [0] Disabled All set-ups FALSE - Uint8
1-74 Start Speed [RPM] SR All set-ups TRUE 67 Uint16
1-75 Start Speed [Hz] SR All set-ups TRUE -1 Uint16
1-76 Start Current 0.00 A All set-ups TRUE -2 Uint32
6 How to Programme the Low Harmonic Drive
VLT AQUA Low Harmonic Drive Operating In-
structions
126 MG.20.T1.02 - VLT
®
is a registered Danfoss trademark
6
