Another easy way of commissioning the frequency
converter is by using the Smart Application Setup (SAS),
which can also be found under the Quick Menu. Follow
the indications on the successive screens for setting up the
applications listed.
[Info] can be used throughout the SAS to see help
information for various selections, settings, and messages.
The following 3 applications are included:
•
Mechanical Brake
•
Conveyor
•
Pump/Fan
The following 4 field-busses can be selected:
•
Profibus
•
Profinet
•
DeviceNet
•
EthernetIP
NOTICE
The start conditions are ignored while in the wizard.
NOTICE
The Smart Set-up runs automatically on the first power-
up of the frequency converter or after a reset to factory
settings. If no action is taken, the SAS screen automat-
ically disappears after 10 min.
4.2 Quick Setup
0-01 Language
Option: Function:
Defines the language to be used in the
display. The frequency converter is
delivered with 4 different language
packages English and German are included
in all packages. English cannot be erased
or manipulated.
[0] * English Part of Language packages 1 - 4
[1] Deutsch Part of Language packages 1 - 4
[2] Francais Part of Language package 1
[3] Dansk Part of Language package 1
[4] Spanish Part of Language package 1
[5] Italiano Part of Language package 1
[6] Svenska Part of Language package 1
[7] Nederlands Part of Language package 1
[10] Chinese Part of Language package 2
[20] Suomi Part of Language package 1
0-01 Language
Option: Function:
[22] English US Part of Language package 4
[27] Greek Part of Language package 4
[28] Bras.port Part of Language package 4
[36] Slovenian Part of Language package 3
[39] Korean Part of Language package 2
[40] Japanese Part of Language package 2
[41] Turkish Part of Language package 4
[42] Trad.Chinese Part of Language package 2
[43] Bulgarian Part of Language package 3
[44] Srpski Part of Language package 3
[45] Romanian Part of Language package 3
[46] Magyar Part of Language package 3
[47] Czech Part of Language package 3
[48] Polski Part of Language package 4
[49] Russian Part of Language package 3
[50] Thai Part of Language package 2
[51] Bahasa
Indonesia
Part of Language package 2
[52] Hrvatski Part of Language package 3
1-20 Motor Power [kW]
Range: Function:
Size
related*
[ 0.09 -
3000.00
kW]
NOTICE
This parameter cannot be adjusted
while the motor is running.
Enter the nominal motor power in kW
according to the motor nameplate data.
The default value corresponds to the
nominal rated output of the unit.
This parameter is visible in LCP if
0-03 Regional Settings is [0] International.
NOTICE
4 sizes down, 1 size up from
nominal unit rating.
1-22 Motor Voltage
Range: Function:
Size
related*
[ 10 -
1000 V]
Enter the nominal motor voltage
according to the motor nameplate
data. The default value corresponds to
the nominal rated output of the unit.
How to Programme
VLT
®
Automation Drive FC 300 Operating Instructions
MG33U402 - Rev. 2013-12-16 83
4 4
