Options
Dual laminator factory fitted option
ISO Magnetic stripe encoding
IAT/JIS capable
Dual high and low coercivity
Tracks 1,2 and 3 (1 track for NTT)
Smart card personalization
SCM Dual Contact/contactless all-in-one reader
Duali Contact/contactless all-in-one reader
Third party contact integration kit
Third party contactless integration kit
Contact station
iCLASS by HID
Prox by HID
Magnetic stripe and smart card field upgradability
L2 laminator field upgrade
Tactile impression field upgradable
High capacity 200 card input hopper
Overlay cartridge assemblies
Replacement print heads
FREQUENTLY ASKED QUESTIONS
GENERAL
Q. What is the print speed of the Datacard
®
CD800™ CLM printer?
A. The print speed for the CD800 CLM printer is:
Up to 210 cards per hour front side YMCK ribbon with front side lamination
Up to 185 cards per hour front side YMCK-K ribbon, back side K with front side lamination
Q: What standards does the magnetic stripe encoder support?
A: The magnetic stripe encoder supports ISO 7811 standards and high- and low-coercivity.
Q: What encoding protocols are supported by the smart card encoder?
A: The encoder supports ISO 14443 A/B and ISO 7816 protocols.
Q. Is the CD800 CLM printer field upgradeable?
A. The CD800 CLM printer is field upgradeable for magnetic stripe encoding, smart card options,
200 card input hopper, and the Commercial Lamination Module by a Datacard authorized service
representative or a trained Datacard Channel Partner.
Q: Can existing CD800 printers in the field be upgraded to add a CLM?
A: Yes, any printers ordered after July 2
nd
, 2012 with serial number: C20000, C19192, C19193 or
C19194.
Q: Is smart card encoding field upgradeable for the CD800 CLM printer?
A: Yes, smart card encoding for the printer can be upgraded in the field by a Datacard authorized
service representative or a trained Datacard Channel Partner.
