Datalogic QuickScan QBT21X1 User Manual

Technical Specifications
Quick Reference Guide 31
Performance Characteristics
Light Source LEDs
Roll (Tilt) Angle
a
a. Based on ISO 15423 specifications
Up to ± 45°
Pitch Angle
a.
± 65°
Skew (Yaw) Angle
a.
± 70°
Field of View 56°± 2°
Depth of Field (Typical)
a
a. 13 mils DOF based on EAN. All other codes are Code 39. All labels grade A,
typical environmental light, 20°C, label inclination 10°
Symbology
Code 39
4 mils: 3.0 to 11.0 cm / 1.2 to 4.3 in
5 mils: 2.0 to 15.0 cm / 0.8 to 5.9 in
7.5 mils: 2.0 to 25.0 cm / 0.8 to 9.8 in
10 mils: 2.0 to 36.0 cm / 0.8 to 14.2 in
13 mils UPC: 1.0 to 45.0 cm / 0.4to 17.7 in
20 mils: up to 70.0 cm / up to 27.5
Minimum
Element Width
4 mil
Print Contrast
Minimum
25% minimum reflectance
