Datalogic QuickScan QBT2500 Quick Reference Guide

Setting Up the Reader
QUICK REFERENCE GUIDE 3
Positioning the Base Station
The base station/charger may be set up in desk applica-
tion standalone or with the additional tilting platform,
which allows to adjust the inclination of the scanner to
provide the most comfortable use depending on the
needs.
Figure 1 - Presentation Position
This position is preferred, if the scanner is to be used in
stand mode and not needed to be often removed from
base station.
Figure 2 - Tilting Platform Position
152
84
169

Datalogic QuickScan QBT2500 Specifications

General

Brand	Datalogic
Model	QuickScan QBT2500
Category	Barcode Reader
Language	English
