08
SETTING UP YOUR OVEN
NAMES OF OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the carton
and oven cavity.
Your oven comes with the following accessories:
Glass tray................................01
Turntable ring assembly..........01
Instruction Manual..................01
Cook Book……...................... 01
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
UTENSILS
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
REMARKS
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a re in the oven.
May cause a re in the oven.
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood will dry out when used in the microwave oven
and may split or crack.
May cause arcing. Transfer food into microwave-safe dish.
Metal shields the food from microwave energy. Metal trim
may cause arcing.
09
F
G
A
C B
E
D
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
TURNTABLE INSTALLATION
Hub (underside)
Grill Rack( Only for Grill series )
Glass tray
Turntable ring assembly
Turntable shaft
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring
assembly must always be used during
cooking.
c. All food and containers of food are always
placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
