DeDietrich CESL C50 User Manual

2.4 Internal Wire Diagram
3. UNIT INSTALLATION
(Fig.1)
The data plates must be accessible at all times, they are used to identify the product and give the
following information:
• Appliance type,
• Serial number,
• Electrical power supply.
3.1 Position of the data plates
9
WIRING DIAGRAM
Thermal
Cut Out
Thermal
Cut Out
Power
Indicator
Heating Indicator
Thermostat
Thermostat
Heating Element
Power
Brown
Blue
Yellow/Green
E
N
L
Q Q
0
1
2
1
0
2
Q
Q
Code: 7755511
N/S:
2000W, 220-240V~
50/60Hz, 0.75MPa
47L
IPX4
UF: N°25334
BDR THERMEA France
57, Rue de la Gare
F-67580 Mertzwiller
CESL C50
7755511 WWYY00000001
