Connecting Your Projector 9
2
Connecting Your Projector
CAUTION: Before you begin any of the procedures in this section, follow the
Safety Instructions as described on page 7.
1 VGA-B input (D-sub) connector 6 VGA-A output
(monitor loop-through)
2 VGA-A input (D-sub) connector 7 Audio output connector
3 S-video connector 8 Security cable slot
4 Composite video connector 9 Audio input connector
5 USB remote connector 10 Power cord connector
3 4 51 2 6 7
810 9
