Dell 2217H User Manual

12 | About Your Monitor
Monitor Specifications
Model P2217H P2317H/P2317HWH
Screen type Active matrix - TFT LCD
Panel technology In-Plane Switching Technology
Aspect ratio 16:9 16:9
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
546.10 mm (21.5 inches)
476.06 mm (18.74 inches)
267.79 mm (10.54 inches)
127484.10 mm
2
(197.6 inch
2
)
584.20 mm (23 inches)
509.18 mm (20.05 inches)
286.42 mm (11.28 inches)
145839.33 mm
2
(226.05
inch
2
)
Pixel pitch 0.248 mm x 0.248 mm 0.265 mm x 0.265 mm
Pixel per inch (PPI) 102 96
Viewing angle 178° (vertical) typical
178° (horizontal) typical
Brightness 250 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
4 Million: 1 (Dynamic)
Display screen coating Anti-Glare with 3H hardness
Backlight White LED edgelight system
Response time (typical) 6 ms (gray to gray)
Color depth 16.7 million colors
Color gamut 82% NTSC (CIE1976)*
Built-in devices • USB 3.0 super-speed hub (with 1 x USB 3.0 upstream port)
• 2 x USB 3.0 downstream ports
• 2 x USB 2.0 downstream ports
Connectivity • 1 x DP 1.2
• 1 x HDMI 1.4
• 1 x VGA
• 1 x USB 3.0 port - Upstream
• 2 x USB 3.0 port - Side
• 2 x USB 2.0 port - Bottom
Border width (edge of
monitor to active area)
11.4 mm (Top/Left/Right)
18.1 mm (Bottom)
11.4 mm (Top/Left/Right)
18.1 mm (Bottom)
Adjustability
