Web Server
You can use the operator panel lockout functionality to create a PIN and choose specific menus to lock. Each
time a locked menu is selected, the user will be prompted to enter the correct PIN. The PIN does not affect
access through the Embedded Web Server.
NOTE: Locking the printer operator panel will prevent a user from entering the printer operator panel
both remotely and at the printer.
To lock operator panel menus:
Open a Web browser. In the address bar, type the IP address of the printer or print server to be
protected using the format: http://ip_address/.
1.
Click Configuration.2.
Under Security, choose the menus you want to protect.3.
Create and re-enter the PIN.
NOTE: PINs must be 4 digits and numeric (0–9).
4.
Click Submit to save the PIN.
To change the PIN, click Reset Form.
5.
Creating an Administrative Password
Creating an administrative password allows a system support person to password-protect printer settings.
To prevent a user from changing a printer setting, the operator panel should be locked and an administrative
password should be set. For more information, see Locking the Operator Panel Menus Using the Embedded
Web Server.
NOTE: When the administrative password is set, the web server will require the password to be
entered before the web server will allow the user to enter any link on the Printer Settings page, with
the exception of the report links.
Open a Web browser.1.
In the address bar, type the network printer or print server IP address, and then press Enter.2.
3.

Dell 2350DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	288 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Multi-Purpose tray input capacity	50 sheets
Envelopes sizes	10, B5, C5, DL
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 90 gsm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Network ready	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
I/O ports	1x IEEE-1284
Networking features	10/100 Base-TX
Compatible operating systems	Windows Vista/7/Server 2008/2003 Server/2000 Server/XP/2000 RH Linux/SuSE Linux NetWare Mac Unix Citrix Metaframe SAP
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Power consumption (printing)	- W
Display	LCD
Maximum duty cycle	60000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	260 x 422 x 369 mm
