Click Start Programs or All Programs Dell Printers your Dell Laser printer model.
Click Dell Printer Software Uninstall.2.
Follow the instructions on the screen.3.
Restart your computer.4.
Insert the Software and Documentation CD, and then follow the instructions on the screen.
If the installation screen does not appear:
In Windows Vista
®
or later, click Computer.
In Windows
®
XP, click Start My Computer.
In Windows 2000, double-click My Computer from your desktop.
a.
Double-click the CD-ROM drive icon, and then double-click setup.exe.b.
When the printer software installation screen appears, click Personal Installation, Network
Installation, or Additional Software Installation.
c.
Follow the instructions on your screen to complete the installation.d.
5.
Dell Toner Management System
Printing Status Window
NOTE: For the Printing Status Window to work properly, bidirectional communication support must be
in place so the printer and computer can communicate. An exception is added to the Windows
®
Firewall to allow this communication.
The Printing Status window displays the status of the printer (Printer Ready, Printer Offline, and Error-Check
Printer) and the name of the job when you send a job to print.
The Printing Status window also displays the level of toner so you can:

Dell 2350DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	288 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Multi-Purpose tray input capacity	50 sheets
Envelopes sizes	10, B5, C5, DL
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 90 gsm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Network ready	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
I/O ports	1x IEEE-1284
Networking features	10/100 Base-TX
Compatible operating systems	Windows Vista/7/Server 2008/2003 Server/2000 Server/XP/2000 RH Linux/SuSE Linux NetWare Mac Unix Citrix Metaframe SAP
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Power consumption (printing)	- W
Display	LCD
Maximum duty cycle	60000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	260 x 422 x 369 mm
