Dell E153FPc User Manual

Dell E153FPc
12
4.3 Power Supply Requirements
4.4 Panel Specification (CPT15”011 ZB)
4.4.1 Panel Feature
4.4.2 Display Characteristics
A/C Line voltage range 100 V ~ 240 V± 10 %
A/C Line frequency range 50 ± 3Hz, 60 ± 3Hz
Input Voltage transients 280 volts AC for 10 sec @40℃
Current 0.6A max. at 100V, 0.35A max. at 240 V
Peak surge current
< 60A peak at 240 VAC and cold starting
< 30A peak at 120VAC and cold starting
Leakage current : < 3.5mA
Power line surge
No advance effects (no loss of information or defect)
with a maximum of 1 half-wave missing per second
