Figure 85. Removing an expansion card from Riser 1B
3. If the expansion card is not going to be replaced, install a filler bracket and close the card retention latch.
NOTE:
You must install a filler bracket over an empty expansion card slot to maintain Federal Communications
Commission (FCC) certification of the system. The brackets also keep dust and dirt out of the system and aid in
proper cooling and airflow inside the system.
NOTE: The numbers on the image do not depict the exact steps. The numbers are for representation of sequence.
Figure 86. Installing filler bracket in the Riser 1A and Riser 1B
Next steps
If applicable, install an expansion card into the expansion card riser.
Installing and removing system components
93
