Dell Inspiron 6000 User Manual

Adding and Replacing Parts 89
Hinge Cover
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as a connector on the back of the computer).
NOTICE: To avoid damaging the system board, you must remove the main battery before you begin working inside
the computer.
1 Follow the procedures in "Before You Begin" on page 75.
2 Remove the hinge cover.:
a Open the display all the way (180 degrees) so that it lies flat against your work surface.
NOTICE: To avoid damaging the hinge cover, do not lift the cover on both sides simultaneously.
b
Insert a scribe in the indent to lift the hinge cover on the right side.
c Ease the hinge cover up, moving from right to left, and remove it.
NOTE: When replacing the hinge cover, first insert the left edge and then press from left to right until the cover
snaps into place.
hinge cover

Dell Inspiron 6000 Specifications

General

Graphics	Intel GMA 900
Wireless	802.11b/g
Memory Type	DDR2 SDRAM
Maximum Memory	2GB
Processor	Intel Pentium M
Display	15.4 inch
Screen Resolution	1280x800 (WXGA) or 1680x1050 (WSXGA+)
RAM	256MB
Storage	40GB to 100GB HDD
Optical Drive	DVD±RW
Operating System	Windows XP Home or Professional
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
Chipset	Intel 915GM
Weight	6.6 lbs
