Dell Latitude 7440 User Manual

Table 13. Camera specifications (continued)
Description Option one Option two Option three
Video Not supported 640 x 360 at 15 fps 640 x 480 at 15 fps
Diagonal viewing angle:
Camera 82 degrees 80 degrees 92 degrees
Infrared camera Not supported 86.6 degrees 77.3 degrees
Clickpad
The following table lists the clickpad specifications of your Latitude 7440.
Table 14. Clickpad specifications
Description Values
Clickpad resolution:
Horizontal
>300 dpi
Vertical
Clickpad dimensions:
Horizontal
133 mm (5.23 in.)
Vertical
72 mm (3.54 in.)
Clickpad gestures For more information about clickpad gestures available on
Windows, see the Microsoft knowledge base article at
support.microsoft.com.
Power adapter
The following table lists the power adapter specifications of your Latitude 7440.
Table 15. Power adapter specifications
Description Option one Option two Option three
Type 60 W AC adapter, USB-C 65 W AC adapter, USB-C 100 W AC adapter, USB-C
Power-adapter dimensions:
Height 22.00 mm (0.866 in.) 28.00 mm (1.10 in.) 26.50 mm (4.80 in.)
Width 66.00 mm (2.598 in.) 51.00 mm (2.01 in.) 60.00 mm (2.36 in.)
Depth 55.00 mm (2.165 in.) 112.00 mm (4.41 in.) 122.00 mm (4.80 in.)
Weight 0.105 kg (0.231 lbs) 0.201 kg (0.443 lbs) 0.33 kg (0.731 lbs)
Input voltage 100 VAC – 240 VAC 100 VAC – 240 VAC 100 VAC – 240 VAC
Input frequency 50 Hz – 60 Hz 50 Hz – 60 Hz 50 Hz – 60 Hz
Input current (maximum) 1.70 A 1.70 A 1.70 A
Output current (continuous)
● 20 V/3 A
● 15 V/3 A
● 9 V/3 A
● 5 V/3 A
● 20 V/3.25 A
● 15 V/3 A
● 9 V/3 A
● 5 V/3 A
● 20 V/5 A
● 15 V/3 A
● 9 V/3 A
● 5 V/3 A
20 Specifications of Latitude 7440

Dell Latitude 7440 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Market positioning	Business
Bus type	DMI2
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4310M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4300 Mobile series
Processor socket	Socket G3
Processor threads	4
Processor codename	Haswell
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	37 W
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 4 GB
AC adapter included	Yes
Intel segment tagging	Enterprise
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Total storage capacity	128 GB
Number of SSDs installed	1
Display diagonal	14 \
Native aspect ratio	16:9
On-board graphics card model	Intel® HD Graphics 4600
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	2 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1250 MHz
Audio system	HD
Front camera resolution	1280 x 720 pixels
WWAN	Installed
Wi-Fi standards	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Recovery operating system	Windows 8.1
Operating system installed	Windows 7 Professional
Processor ARK ID	80373
Processor package size	37.5 x 37.5 x 4.7 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Battery capacity	45 Wh
Battery life (max)	- h
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	231.5 mm
Width	337 mm
Height	21 mm
Weight	1630 g
