Dell Latitude 7440 User Manual

Multiple display support matrix
The following table lists the multiple display support matrix for your Latitude 7440.
Table 21. Multiple display support matrix
Graphics Card Direct Graphics Controller
Direct Output Mode
Supported external displays
with computer internal display
on
Supported external
displays with computer
internal display off
Intel Iris X
e
Graphics Not applicable 3 4
Hardware security
The following table lists the hardware security of your Latitude 7440.
Table 22. Hardware security
Hardware security
Trusted Platform Module (TPM) 2.0 discrete
FIPS 140-2 certification for TPM
Trusted Computing Group (TCG) Certification for TPM
Contacted smart card and Control vault 3
Contactless smart card, NFC, and Control vault 3
SED SSD NVMe, SSD and HDD (Opal and non-Opal) per SDL
Fingerprint reader in power button tied to Control vault 3
One wedge-shaped lock slot
SED (Opal 2.0 only - PCIe Interface)
Windows Hello - Fingerprint Reader (optional)
Mechanical privacy shutter for camera (only for metal laptops)
Smart-card reader
Contactless smart-card reader
This section lists the contactless smart-card reader specifications of your Latitude 7440.
Table 23. Contactless smart-card reader specifications
Title Description Dell ControlVault 3 contactless
smart-card reader with NFC
Felica Card Support Reader and software capable of
supporting Felica contactless cards
Yes
ISO 14443 Type A Card Support Reader and software capable of
supporting ISO 14443 Type A contactless
cards
Yes
ISO 14443 Type B Card Support Reader and software capable of
supporting ISO 14443 Type B contactless
cards
Yes
Specifications of Latitude 7440 25

Dell Latitude 7440 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Market positioning	Business
Bus type	DMI2
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4310M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4300 Mobile series
Processor socket	Socket G3
Processor threads	4
Processor codename	Haswell
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	37 W
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 4 GB
AC adapter included	Yes
Intel segment tagging	Enterprise
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Total storage capacity	128 GB
Number of SSDs installed	1
Display diagonal	14 \
Native aspect ratio	16:9
On-board graphics card model	Intel® HD Graphics 4600
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	2 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1250 MHz
Audio system	HD
Front camera resolution	1280 x 720 pixels
WWAN	Installed
Wi-Fi standards	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Recovery operating system	Windows 8.1
Operating system installed	Windows 7 Professional
Processor ARK ID	80373
Processor package size	37.5 x 37.5 x 4.7 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Battery capacity	45 Wh
Battery life (max)	- h
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	231.5 mm
Width	337 mm
Height	21 mm
Weight	1630 g
