Dell Latitude D510 - Back View; Bottom View

18 Quick Reference Guide
www.dell.com | support.dell.com
Back View
CAUTION: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store
your computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting
the airflow can damage the computer or cause a fire.
Bottom View
air vent
USB connectors (2)
modem connector (RJ-11)
network connector (RJ-45)
S-video TV-out connector
parallel connector
serial connector
video connector
AC adapter connector
fan
battery
docking device slot
communications
cover
memory module cover
battery-bay latch release
hard drive
