Dell OptiPlex 580 Setup And Features Information

1
Connect the monitor using only one of the following cables:
2
Connect the network cable
(optional).
a The blue VGA cable. b The DisplayPort cable.
3
Connect the modem
(optional).
4 Connect the
USB keyboard or
mouse (optional).
5 Connect the
power cable(s).
6 Press the power button on the monitor and the computer.
Quick Setup
WARNING: Before you
begin any of the procedures
in this section, read the
safety information that
shipped with your
computer. For additional
best practices information,
see www.dell.com/
regulatory_compliance.
NOTE: Some devices
may not be included if
you did not order them.
78N8Wam0.fm Page 5 Monday, January 11, 2010 2:58 PM

Dell OptiPlex 580 Specifications

General

Chipset	AMD 785G
Optical Drive	DVD-ROM or DVD+/-RW
Audio	Integrated High Definition Audio
Memory	Up to 8GB DDR3
Graphics	ATI Radeon HD 4200 integrated graphics
Operating System	Windows 7, Ubuntu
Networking	Integrated Broadcom 5761 Ethernet LAN 10/100/1000
Ports	USB 2.0, VGA, DisplayPort, serial
Power Supply	255W
Form Factor	Mini Tower, Desktop
