Dell OptiPlex 760 Technical Guidebook

DELL™ OPTIPLEX™ 760 TECHNICAL GUIDEBOOK V1.0
15
DETAILED ENGINEERING SPECIFICATIONS
SYSTEM DIMENSIONS (PHYSICAL)
NOTE: System Weight and Shipping Weight is based on a typical configuration and may vary based on PC
configuration. A typical configuration includes: integrated graphics, one hard drive, one optical drive, and
one diskette drive.
SYSTEM BOARD CONNECTOR MAXIMUM ALLOWABLE DIMENSIONS
MT DT SFF USFF
Chassis Volume (liters) 33.0 16.0 10.7 6.0
Chassis Weight (pounds/kilograms) 25.8 / 11.7 18.2 / 8.26 15 / 6.80 10 / 4.54
Chassis Dimensions: (HxWxD)
Height (inches/centimeters) 16.3 / 41.4 4.5 / 11.4 3.65 / 9.26 10.3 / 26.4
Width (inches/centimeters) 7.3 / 18.5 15.7 / 39.9 12.4 / 31.4 3.5 / 8.9
Depth (inches/centimeters) 17.3 / 43.9 13.9 / 35.3 13.4 / 34 9.9 / 25.3
Shipping Weight (pounds/kilograms - includes packaging materials) 43.5 / 19.73 28 / 12.7 21.3 / 9.66 26.1 / 11.84
Height (inches/centimeters)
22.38 /
56.85
20.63 / 52.4
20.88 /
50.04
19.88 / 50.5
Width (inches/centimeters)
22.25 /
56.52
20.31 /
51.59
19.38 /
49.23
17.5 / 44.45
Depth (inches/centimeters) 14.25 / 36.2
11.75 /
29.85
10.63 / 27
10.44 /
26.52
Packaging Parameters (HxWxD)
MT DT SFF USFF
PCI Slots
2 2 1
Height (inches/centimeters)
4.376 /
11.115
2.731 / 6.89
Length (inches/centimeters)
7.4 /
18.796*
6.6 / 16.764
PCIe x16 Slots
1 1 1
Height (inches/centimeters)
4.376 /
11.115
2.731 / 6.89
Length (inches/centimeters)
7.4 /
18.796*
6.6 / 16.764
PCIe x1 Slots
1
Height (inches/centimeters)
4.376/11.11
5
Length (inches/centimeters)
7.4 /
18.796*
Risers: (replaces 1 PCI slot and 1 PCIe slot on DT system board)
Combo Full Height Riser with 1 PCI and 1 PCIe connector (HxL)
1
Height (inches/centimeters)
4.376/11.11
5
Length (inches/centimeters)*
,
** 6.6/16.764
Dual Full Height Riser with 2 PCI connectors (HxL)
1
Height (inches/centimeters)
4.376/11.11
5
Length (inches/centimeters)*
,
** 6.6/16.764
* Card length can be longer than standard Half-Length Card but cannot be a Full-Length Card.
** 6.9/17.53 in/cm is longer than the standard Half-Length Card

Dell OptiPlex 760 Specifications

General

Optical Drive	DVD-ROM, DVD+/-RW
Audio	Integrated High Definition Audio
Processor	Intel Core 2 Duo
Chipset	Intel Q43 Express
Memory	Up to 8GB DDR2
Storage	Up to 1TB SATA HDD
Graphics	Integrated Intel Graphics Media Accelerator 4500
Network	Integrated Gigabit Ethernet
Ports	USB 2.0, VGA, DisplayPort
Operating System	Windows Vista, Windows XP
Form Factor	Mini Tower, Desktop, Small Form Factor, Ultra Small Form Factor
Power Supply	235W (Small Form Factor)
