Dell OptiPlex 760 Technical Guidebook

DELL™ OPTIPLEX™ 760 TECHNICAL GUIDEBOOK V1.0
21
GRAPHICS/VIDEO CONTROLLER
NOTE: MT supports full height card, DT supports low profile card or full height card with optional riser. SFF
supports low profile card.
INTEGRATED INTEL GMA 4500
MT DT SFF USFF
Bus Type
Integrated
GPU core clock
Gen5 core @ 667 350 MHz Integrated and with
350MHz 24 bit RAMDAC
Frame Buffer Memory (onboard and shared) Size and Speed
XP: Up to 1GB shared system memory with 2GB
system memory
Vista: Up to 2GB shared system memory with 4GB
system memory
Maximum power consumption
4 W
Overlay Planes
Yes
Maximum Color Depth
32 bit
Maximum Vertical Refresh Rate
85 Hz
Multiple Display Support
Yes
Operating Systems Graphics/ Video API Support
OpenGL 2.0/DirectX 10.0
Supported Resolutions and Max Refresh Rates (Hz) (Note: Analog and/
or digital)
Up to 2560x11600 @ 60Hz (DP)
Up to 1920x1200 @ 60Hz (DVI & VGA)
Up to 1600x1200 @ 85Hz (VGA only)
External connectors
VGA, DisplayPort DVI
Environmental Operating Conditions (Non-Condensing):
Operating Temperature Range
0° to 106° C (32° to 223° F)
Relative Humidity Range
20% to 80% (non-condensing)
Altitude Range
–15.2 to 3048 m (–50 to 10,000 ft)
DisplayPort (MT/DT/SFF Only)
Bus Type
AUX 1, 2, 4 lanes
Maximum supported resolution
Up to 2560x1600 @ 60Hz
Maximum power consumption
N/A
External connectors
DisplayPort
Bus Type
sDVO
Maximum supported resolution
Up to 1920x1566 @ 60 Hz
Dimensions of full height card inches/centimeters (L x H)
5.75x2.75in/
14.61x6.99c
m
Dimensions of low profile card inches/centimeters (L x H)
5.75x2.75in/
14.61x6.99cm
Maximum power consumption
N/A
External connectors
DVI
DVI (Digital) Adder Card
1
Up to 1.7 GB of system memory may be allocated to support integrated graphics, depending on operating system, system memory size and other
factors.
2
DVI and VGA can be used concurrently for multi-monitor display in DOS. The DisplayPort controller does not support multi-monitor display in DOS
3
Populating a discrete graphics card in the x16 slot disables onboard video.

Dell OptiPlex 760 Specifications

General

Optical Drive	DVD-ROM, DVD+/-RW
Audio	Integrated High Definition Audio
Processor	Intel Core 2 Duo
Chipset	Intel Q43 Express
Memory	Up to 8GB DDR2
Storage	Up to 1TB SATA HDD
Graphics	Integrated Intel Graphics Media Accelerator 4500
Network	Integrated Gigabit Ethernet
Ports	USB 2.0, VGA, DisplayPort
Operating System	Windows Vista, Windows XP
Form Factor	Mini Tower, Desktop, Small Form Factor, Ultra Small Form Factor
Power Supply	235W (Small Form Factor)
