Dell P2011H User Manual

Dell P2011H
37 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #3 background imageLoading...
Page #3 background image
Product Features
The Dell™Professional P2011H flat panel display has an active matrix, thin-film transistor (TFT), liquid crystal display (LCD), and LED backlight. The monitor
features include:
50.80cm(20inches)viewableareadisplay(Measureddiagonally).1600 X 900 resolution, plus full-screen support for lower resolutions.
Tilt, swivel, vertical extension and rotate adjustment capability.
Removable pedestal and Video Electronics Standards Association (VESA) 100 mm mounting holes for flexible mounting solutions.
Plug and play capability if supported by your system.
On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
Software and documentation media includes an information file (INF), Image color Matching File (ICM), PowerNap software application and product
documentation.
Energy Saver feature for Energy Star compliance.
Security lock slot.
Asset Management Capability.
Capability to switch from wide aspect to standard aspect ratio while maintaining the image quality.
EPEAT Gold Rating.
Halogen Reduced.
Arsenic-Free glass and Mercury Free for Panel only.
High Dynamic Contrast Ratio (DCR).
0.5 W standby power when in sleep mode.^
Energy Gauge shows the energy level being consumed by the monitor in real time.
PowerNap Software included (comes in the CD attached with the monitor).
^Based on measurement of standby power consumption using VGA input.
Identifying Parts and Controls
Front View
l DVI Cable
l USB up stream cable (enables the USB ports on the monitor)
l Drivers and Documentation media
l Quick Setup Guide
l Product and Safety Information Guide

Other manuals for Dell P2011H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell P2011H and is the answer not in the manual?

Dell P2011H Specifications

General IconGeneral
3DNo
HD type-
Pixel pitch0.277 x 0.277 mm
Aspect ratio16:9
Display diagonal20 \
Display resolution1600 x 900 pixels
Viewable size diagonal508 mm
Viewing angle, vertical160 °
Contrast ratio (dynamic)2000000:1
Display number of colors16.78 million colors
Viewing angle, horizontal170 °
Display brightness (typical)250 cd/m²
Supported graphics resolutions1600 x 900
HDCPYes
USB hub version2.0
USB Type-A downstream ports quantity2
Ethernet LAN (RJ-45) ports0
CertificationEPEAT Gold
Product colorBlack
Market positioningBusiness
Compliance industry standardsTCO 5.0
Panel mounting interface100 x 100 mm
Input current1.5 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)45 W
Power consumption (standby)0.5 W
Power consumption (typical)20 W
Operating altitude0 - 4850 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
Package weight5560 g
Cables includedDVI, USB, VGA
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)171.92 mm
Height (with stand)435.85 mm
Weight (with stand)- g
Depth (without stand)61.50 mm
Width (without stand)481.17 mm
Height (without stand)287.5 mm
Weight (without stand)2700 g
