Dell P2011H User Manual

Electrical Specifications
Model
P2011H
Video input signals
Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance
Digital DVI-
D TMDS, 600mV for each differential line, positive polarity at 50 ohm input
impedance
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
AC input voltage/frequency/current
100 to 240 VAC/50 or 60 Hz + 3 Hz/1.5 A (Max.)
Inrush current
120V:30A (Max.)
240V:60A (Max.)
Physical Characteristics
Model
P2011H
Connector type
15-pin D-subminiature, blue connector; DVI-D, white
connector
Signal cable type
Digital: Detachable, DVI-D, Solid pins, shipped
detached from the monitor
Analog: Detachable, D-Sub, 15 pins, shipped attached
to the monitor
Dimensions (with stand)
Height (extended)
435.85 mm (17.16 inches)
Height (compressed)
315.85 mm (12.44 inches)
Width
481.17 mm (18.94 inches)
Depth
171.92 mm (6.77 inches)
Dimensions (without stand)
Height
287.57 mm (11.32 inches)
Width
481.17 mm (18.94 inches)
Depth
61.50 mm (2.42 inches)
Stand dimensions
Height (extended)
360.60 mm (14.20 inches)
Height (compressed)
240.60 mm (9.47 inches)
Width
249.92 mm (9.84 inches)
Depth
171.92 mm (6.77 inches)
Weight
Weight with packaging
5.56 kg (12.23 lb)
Weight with stand assembly and cables
4.56 kg (10.03 lb)
Weight without stand assembly

Dell P2011H Specifications

General

3D	No
HD type	-
Pixel pitch	0.277 x 0.277 mm
Aspect ratio	16:9
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Viewable size diagonal	508 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	2000000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1600 x 900
HDCP	Yes
USB hub version	2.0
USB Type-A downstream ports quantity	2
Ethernet LAN (RJ-45) ports	0
Certification	EPEAT Gold
Product color	Black
Market positioning	Business
Compliance industry standards	TCO 5.0
Panel mounting interface	100 x 100 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	45 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Operating altitude	0 - 4850 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package weight	5560 g
Cables included	DVI, USB, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	171.92 mm
Height (with stand)	435.85 mm
Weight (with stand)	- g
Depth (without stand)	61.50 mm
Width (without stand)	481.17 mm
Height (without stand)	287.5 mm
Weight (without stand)	2700 g
