Dell P2018H User Manual

56 │ Troubleshooting
Troubleshooting
WARNING: Before you begin any of the procedures in this section,
follow the Safety Instructions.
Self-test
Your monitor provides a self-test feature that allows you to check if your monitor is
functioning properly. If your monitor and computer are properly connected but the
monitor screen remains dark, run the monitor self-test by performing the following
steps:
1.
Turn off both your computer and the monitor.
2.
Disconnect all video cables from the monitor. This way, the computer doesn’t
have to be involved.
3.
Turn on the monitor.
If the monitor is working correctly, it detects that there is no signal and one of the
following message appears. While in self-test mode, the power LED remains white.
Dell P2418HZ
Dell 20 Monitor
No VGA Cable
www.dell.com/support/monitors
?
P2018H
The display will go into Standby Mode in 4 minutes.
or
Dell P2418HZ
Dell 20 Monitor
No HDMI Cable
www.dell.com/support/monitors
?
P2018H
The display will go into Standby Mode in 4 minutes.
or

Dell P2018H Specifications

General

On/off switch	-
Power management	Yes
TV tuner integrated	No
Cables included	AC, DisplayPort, VGA
Panel type	TN
Color gamut	84 %
Pixel pitch	0.271 x 0.263 mm
Screen shape	Flat
Pixel density	94 ppi
Backlight type	LED
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	56 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal	494.11 mm
Viewable size, vertical	236.34 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	4000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	433.92 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1600 x 900
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	1
USB Type-A downstream ports quantity	4
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	39 W
Power consumption (standby)	0.2 W
Power consumption (typical)	9.7 W
Power consumption (PowerSave)	13 W
Package depth	511.05 mm
Package width	167.89 mm
Package height	352.04 mm
Package weight	6130 g
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12191 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Product color	Black
Market positioning	Business
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	18.1 mm
Bezel width (side)	13.8 mm
Depth (with stand)	180 mm
Width (with stand)	461.5 mm
Height (with stand)	468.8 mm
Weight (with stand)	4730 g
Bezel width (bottom)	18.8 mm
Depth (without stand)	50.1 mm
Height (without stand)	273.2 mm
Weight (without stand)	2400 g
