Dell PowerEdge R610 Getting Started With

Guide de mise en route 31
• Microsoft Windows Server 2003, éditions Standard et Enterprise (x64)
avec SP2
• Microsoft Windows Server 2003 éditions Web, Standard et Enterprise
(32 bits x86) Gold
• Microsoft Windows Server 2003, éditions Standard, Enterprise et
DataCenter (x64) Gold
• Microsoft Windows Small Business Server 2003 R2, éditions Standard et
Premium avec SP2
•Red Hat
®
Enterprise Linux
®
ES et AS 4.7 (x86)
• Red Hat Enterprise Linux ES et AS 4.7 (x86_64)
• Red Hat Enterprise Linux 5.2 Server (x86_32)
• Red Hat Enterprise Linux 5.2 Server (x86_64)
• SUSE Linux Enterprise Server 10 SP2 (x86_64)
•VMware
®
ESX Version 4.0 et 3.5, Mise à jour 4 (si disponible)
• VMware ESXi Version 4.0 et 3.5, Mise à jour 4 (si disponible)
REMARQUE : Pour obtenir les informations les plus récentes sur les systèmes
d'exploitation pris en charge, rendez-vous sur le site www.dell.com.
Autres informations utiles
AVERTISSEMENT : Consultez les informations sur la sécurité et les
réglementations fournies avec votre système. Les informations sur la garantie se
trouvent soit dans ce document, soit à part.
• La documentation fournie avec le rack indique comment installer
le système dans un rack.
• Le document
Hardware Owner's Manual (Manuel du propriétaire)
présente les caractéristiques du système et contient des informations
de dépannage et des instructions d'installation ou de remplacement
des composants. Il est disponible en ligne sur le site
support.dell.com.

Dell PowerEdge R610 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
HDD speed	15000 RPM
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-RW
Total storage capacity	146 GB
Maximum storage capacity	12 TB
Number of HDDs supported	6
Graphics card	G200
Graphics card family	Matrox
Memory slots	12
Internal memory	8 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	4 x 2 GB
Maximum graphics card memory	8 MB
Networking features	Gigabit Ethernet
Ports quantity	11
Number of slots	3
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	717 W
Operating system installed	-
Compatible operating systems	SQL Server 2008 R2 Windows Small Business Server 2008 Windows Essential Business Server 2008 Windows Server 2008 SP2, x86/x64 (x64 Hyper-V) Windows Server 2008 R2, x64 (Hyper-V v2) Windows HPC Server 2008 SUSE Linux Enterprise Server Red Hat Enterprise Linux Sun Solaris
Sustainability certificates	ENERGY STAR
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Chassis type	Rack (2U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	772 mm
Width	482 mm
Height	42.6 mm
Weight	17690 g
