Dell S2230MX User Manual

Down
Use the Down key to adjust (decrease ranges) items in the OSD menu.
C
OK
Use the OK key to confirm your selection.
D
Back
Use the Back key to go back to the previous menu.
Using the On-Screen Display (OSD) Menu
Accessing the Menu System
NOTE: If you change the settings and then either proceed to another menu or exit the OSD menu, the monitor automatically saves those changes. The changes are also
saved if you change the settings and then wait for the OSD menu to disappear.
1.
Press the
button to open the OSD menu and display the main menu.
Main Menu

Dell S2230MX Specifications

General

3D	No
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Response time	2 ms
Display diagonal	21.5 \
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI ports quantity	-
DVI-I ports quantity	0
Product color	Black
Market positioning	Business
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	20 W
Power consumption (standby)	0.5 W
Power consumption (typical)	13 W
Operating altitude	- m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Width (with stand)	519.6 mm
Height (with stand)	391.36 mm
Depth (without stand)	59.4 mm
Width (without stand)	520.64 mm
Height (without stand)	326.02 mm
Weight (without stand)	3960 g
