Dell V515W User Manual

10 Repeat steps 4 through 6.
11 From the Print or “Pages to Print” pop-up menu, choose to print the even-numbered pages.
12 Click Print.
Managing print jobs
Setting your printer as the default printer
Your printer should be selected automatica lly from the Pri nt dialog when you send a print job. If you have to manually
select your printer, then it is not the default printer.
To set the default printer:
For Windows users
1 Click , or click Start and then click Run.
2 In the Start Search or Run box, type control printers.
3 Press Enter, or click OK.
The printer folder opens.
4 Right-click the printer, and then select Set as Default Printer.
For Macintosh users
1 From the Apple menu, choose System Preferences.
2 Click Print & Fax.
3 Select the printer from the Default Printer pop-up menu, or select the printer and click Make Default, depending
on your operating system.
Changing the printing mode
To conserve ink, you can change the default printing mode for all print jobs to Draft or Quick Print. It uses less ink
and is ideal for printing text-only documents. If you need to print photos or other high-quality documents, then you
can select a different mode from the Print dialog before sending the print job.
To change the default print mode:
For Windows users
1 Click , or click Start and then click Run.
2 In the Start Search or Run box, type control printers.
3 Press Enter, or click OK.
The printer folder opens.
4 Right-click the printer, and then select Printing Preferences.
5 Select Quick Print as the printing mode.
Printing
50

Dell V515W Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	33 ppm
Print speed (color, normal quality, A4/US Letter)	30 ppm
Digital sender	No
Number of print cartridges	2
Scanner type	Flatbed scanner
Copy speed (black, normal quality, A4)	25 cpm
Copy speed (color, normal quality, A4)	21 cpm
Maximum input capacity	100 sheets
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Compatible memory cards	Microdrive, MiniSD, MMC, MS Duo, MS Pro, SD, SDHC
Dimensions (WxDxH)	487 x 341 x 204 mm
Wireless technology	802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	64 GB
Color all-in-one functions	copy, print, scan
Envelopes sizes	6 3/4, 7 3/4, 9, 10, B5, C5, C6, DL
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Iron-On Transfers, Labels, Photo paper, Plain paper, Transparencies
Non-ISO print media sizes	2l, Executive (184 x 267mm), hagaki card, index card, l, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Faxing	Mono faxing
