Dell XPS 15 7590 User Manual

1. Power-adapter port
Connect a power adapter to provide power to your computer and charge the battery.
2. USB 3.1 Gen 1 port with PowerShare
Connect peripherals such as external storage devices and printers.
Provides data transfer speeds up to 5 Gbps. PowerShare enables you to charge your USB devices even when your computer is turned off.
NOTE: If the charge on your computer’s battery is less than 10 percent, you must connect the power adapter to charge your computer, and USB
devices connected to the PowerShare port.
NOTE: If a USB device is connected to the PowerShare port before the computer is turned off or in hibernate state, you must disconnect and
connect it again to enable charging.
NOTE: Certain USB devices may not charge when the computer is turned off or in a sleep state. In such cases, turn on the computer to charge the
device.
3. HDMI port
Connect to a TV or another HDMI-in-enabled device. Provides video and audio output.
4. Thunderbolt 3 (USB 3.1 Gen 2 Type-C) port with Power delivery
Supports USB 3.1 Gen 2, DisplayPort 1.2, Thunderbolt 3 and also enables you to connect to an external display using a display adapter. Provides data
transfer rates up to 10 Gbps for USB 3.1 Gen 2 and up to 40 Gbps for Thunderbolt 3. Supports Power Delivery that enables a two-way power supply
between devices. Provides up to 5V/3A power output that enables faster charging.
NOTE: Adapters (sold separately) are required to connect standard USB and DisplayPort devices.
5. Headset port
Connect headphones or a headset (headphone and microphone combo).
Base
1. Power button with optional fingerprint reader
Press to turn on the computer if it is turned off, in sleep state, or in hibernate state.
When the computer is turned on, press the power button to put the computer into a sleep state; press and hold the power button for 10 seconds to force
shut down the computer.
If the power button has a fingerprint reader, place your finger on the power button to log in.
NOTE: You can customize power-button behavior in Windows. For more information, see Me and My Dell at w ww.dell.com/support/manuals.
NOTE: The power-status light on the power button is available only on computers without the fingerprint reader.
Computers shipped with the fingerprint reader integrated on the power button will not have the power-status light on the power button.
2. Right-click area
Press to right-click.
3. Touchpad
Move your finger on the touchpad to move the mouse pointer. Tap to left-click and two-finger tap to right-click.
4. Left-click area
Press to left-click.
Display

Dell XPS 15 7590 Specifications

General

Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
System bus rate	8 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1440
Processor threads	8
Processor codename	Coffee Lake
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
On-board graphics card	Yes
On-board graphics card ID	0x3E9B
Discrete graphics card model	NVIDIA® GeForce® GTX 1650
On-board graphics card model	Intel® UHD Graphics 630
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
Maximum on-board graphics card memory	64 GB
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Form factor	Clamshell
Product type	Laptop
Product color	Silver
Display diagonal	15.6 \
Native aspect ratio	16:9
Internal memory	8 GB
Memory clock speed	2666 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	2 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	256 GB
Compatible memory cards	SD
Number of SSDs installed	1
Antenna type	2x2
Bluetooth version	5.0
Top Wi-Fi standard	-
Battery capacity	56 Wh
Number of battery cells	3
AC adapter power	130 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Pointing device	Touchpad
Processor ARK ID	191075
Processor package size	42 x 28 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0

Weight and Dimensions

Depth	235 mm
Width	357 mm
Weight	1800 g
Height (rear)	17 mm
Height (front)	11 mm
